5050 SMD LED Modules
Home >> Promotional Products>> LED Modules >> 5050 SMD LED Modules
It is designed for Illuminated signages, channel letters, led lighting box, etc.
Specification:
|
Dimension |
44(L)*15(W)*6.8(H) |
||||||
|
LED No |
2 pcs SMD5050 LED |
||||||
|
Voltage |
DC12V |
||||||
|
View angle |
155° |
||||||
|
Current |
460mA |
||||||
|
Watts |
0.48W |
||||||
|
Lumen |
46 |
8 |
25 |
10.5 |
13 |
||
|
Color |
White |
Blue |
Green |
Yellow |
Red |
||
|
Drive method |
Constant Current Drive |
||||||
|
Max connection |
50 pcs per chain |
||||||
|
Working temp |
-20～+60℃ |
||||||
|
Protection Degree |
IP65 |
||||||
|
Cover material |
Milky white ABS |
||||||
|
Warranty |
3 years |
||||||
|
Certification |
CE&RoHS |
||||||
|
Model |
OML-2W5050 |
OML-2B5050 |
OML -2G5050 |
OML -2Y5050 |
OML-2R5050 |
||
Feature:
1. 95% transmittance lens, Wide view angle 155°
2. Constant Current Driving method, 50 pcs per Chain.
3. Suitable for Super Thin channel letters and light boxes, No Spot, No Shadow.
4. Injection molding process. IP 67, waterproof.
5. Exposed Aluminum pcb design, perfect heat dissipation
6. Adopt Top 5050 SMD LED, Original Epistar chip from Taiwan
7. Long life span, 50,000 hrs
